Broke my undercarriage plastic thing

Discussion in 'Gen II Prius Care, Maintenance and Troubleshooting' started by footprintx, Jun 8, 2008.

Social Buttons

  1. footprintx

    footprintx New Member

    Joined:
    May 3, 2008
    Messages:
    38
    Likes Received:
    0
    Location:
    Riverside, CA
    Your Vehicle Year:
    2004 Prius
    I broke that plastic piece that runs along the front part of the undercarriage of the car, and now it hangs a little down and catches on speed bumps and such. I took it in to my local Toyota Dealer and the dealer said a new plastic piece would cost $345, but he could jerry rig it for $40 and if it didn't work he'd apply that $40 to the cost of the re-do.

    Well, it didn't work, this was a few days ago and as soon as I hit 75 on the freeway, it came down and started dragging.

    Any ideas on what I should do? Is that piece even necessary or will not having it significantly decrease my mpg? Do you think they'd have one on the local pick-a-part? Could I just bolt on a large piece of graphite to the plastic that's still stable down there? It's up near the front and the holes where the clips attach are busted except for one of them.
  2. Neicy

    Neicy New Member

    Joined:
    Apr 29, 2007
    Messages:
    821
    Likes Received:
    2
    Location:
    Wakefield, MA.
    Your Vehicle Year:
    2012 Prius
    Model:
    Three
    You mean like this, only worse? I got some fender washers but haven't gotten under it to see if it works yet. I think I will duct tape mine before I would put out $345.00 to get it replaced.

    Attached Files:

  3. footprintx

    footprintx New Member

    Joined:
    May 3, 2008
    Messages:
    38
    Likes Received:
    0
    Location:
    Riverside, CA
    Your Vehicle Year:
    2004 Prius
    Yes, exactly! Only ... worse. It used to look like that. Look out, once it starts hanging like that it starts getting caught on everything: speed-bumps, steep-driveways. Should I just duct-tape it?
  4. wchardin

    wchardin Advertise Here

    Joined:
    Mar 16, 2008
    Messages:
    2,050
    Likes Received:
    1
    Location:
    Owensboro, KY
    Your Vehicle Year:
    2008 Prius


    Did you take it to a Toyota dealer or a different type dealer? I would try and shop around. $345 seems much for that. A local dealer might be able to drill holes and fix it flush to the rest of the undercarriage. Good luck and let us know if you get it fixed.
  5. Scott_R

    Scott_R Member

    Joined:
    Jul 20, 2006
    Messages:
    360
    Likes Received:
    5
    Location:
    Long Island
    Your Vehicle Year:
    2012 Prius
    Model:
    Four


    When I did something similar to my car, I used some epoxy (the two-part putty stuff) to fix it.

    I removed the bolt, kneaded up some putty, and smoothed it over the area, overlapping it over the existing plastic on the top and bottom and smoothing it relatively flat. I pushed the screw through a bit, just enough to make a modest hole. When it dried, I reattached it. Worked perfectly.
  6. GatorJZ

    GatorJZ New Member

    Joined:
    May 25, 2008
    Messages:
    267
    Likes Received:
    4
    Location:
    Florida
    Your Vehicle Year:
    Other Hybrid
    Just to make it easier for you, it is called a "splash guard".
  7. patsparks

    patsparks An Aussie perspective

    Joined:
    Jul 12, 2007
    Messages:
    10,665
    Likes Received:
    538
    Location:
    Adelaide South Australia
    Your Vehicle Year:
    2004 Prius
    Model:
    N/A
    PriusChat Shop, get the alloy undertray. It will cost a little more but is much tougher for next time.
  8. footprintx

    footprintx New Member

    Joined:
    May 3, 2008
    Messages:
    38
    Likes Received:
    0
    Location:
    Riverside, CA
    Your Vehicle Year:
    2004 Prius
    @patsparks: couldn't seem to find that on PriusChat Shop, by search or browsing. :(
  9. GatorJZ

    GatorJZ New Member

    Joined:
    May 25, 2008
    Messages:
    267
    Likes Received:
    4
    Location:
    Florida
    Your Vehicle Year:
    Other Hybrid


    Search for BT Tech Skid Plate.
  10. Syclone

    Syclone Member

    Joined:
    May 9, 2006
    Messages:
    542
    Likes Received:
    5
    Your Vehicle Year:
    2006 Prius
    Model:
    Five
    I just had mine replaced. It was 61.00 plus labor ( dealer did it free because one of the mechanics had screwed up a service item). Find another dealer!!
  11. Neicy

    Neicy New Member

    Joined:
    Apr 29, 2007
    Messages:
    821
    Likes Received:
    2
    Location:
    Wakefield, MA.
    Your Vehicle Year:
    2012 Prius
    Model:
    Three
  12. efusco

    efusco Troll Slayer Staff Member

    Joined:
    Nov 26, 2003
    Messages:
    19,842
    Likes Received:
    1,067
    Location:
    Nixa, MO
    Your Vehicle Year:
    2004 Prius
    Model:
    N/A
    I also suggest the skid plate...it doesn't hang down like the plastic one and it adds the benefit of added protection to the underside....and is cheaper than the plastic replacement to boot.
  13. ZC1

    ZC1 Junior Prius Owner

    Joined:
    Apr 18, 2008
    Messages:
    711
    Likes Received:
    10
    Location:
    Metro Detroit
    Your Vehicle Year:
    2008 Prius
    If you have all the pieces, there is an inexpensive but extremely durable solution in two words:

    JB Weld

    It's not only for metal but plastic too. Find it in your autoparts store.

    ZC1
  14. footprintx

    footprintx New Member

    Joined:
    May 3, 2008
    Messages:
    38
    Likes Received:
    0
    Location:
    Riverside, CA
    Your Vehicle Year:
    2004 Prius
    so ... i have it taped now, and am seriously leaning towards that skid plate, more from a lack of options than anything else. I've read the two reviews about the skid plate, efusco and fboyle2000s.

    i talked to the guy at the Toyota Dealership, and he said he'd install it for me, since his jerry-rig didn't work.

    Has anybody else bought this thing? What do they think? Efusco, once you got more clearance, did that help with the noise (ie: was it the plate reflecting the road noise, or was it the part of yours that was rubbing up against the plate?) is there anything i should tell them to save them some time / incorrect installation?

    thanks for all y'alls advice.
  15. hyo silver

    hyo silver Awaaaaay

    Joined:
    Mar 2, 2005
    Messages:
    15,142
    Likes Received:
    1,371
    Location:
    off into the sunset
    Your Vehicle Year:
    2004 Prius
    Model:
    N/A
    $345?! Holy crap. Twist a short sheet-metal screw into it and call it done. Duct tape will work, but only until the first rain.
  16. Rokeby

    Rokeby Member

    Joined:
    Jan 21, 2008
    Messages:
    3,006
    Likes Received:
    688
    Location:
    Ballamer, Merlin
    Your Vehicle Year:
    2008 Prius
    Forget the duct tape. Try Gorilla Tape -- Home Depot has it. Black, opaque,
    very high tack, lots of fibers.

    Just as good as the "300 MPH" mil spec duct tape that a Marine buddy
    "liberated" and gave me some while back.
