Rear License Plate Installation, Gen III

Discussion in 'Gen 3 Prius Accessories and Modifications' started by xs650, Aug 5, 2010.

  1. xs650

    xs650 Senior Member

    Joined:
    Jul 2, 2010
    4,539
    1,433
    9
    Location:
    Northern California
    Vehicle:
    2010 Prius
    Model:
    II
    I decided to install my Gen III rear plate with a solid 4 point mount instead of the stock 2 point mount. The labels on the pictures should make them self explanatory.

    I also but some EPDM rubber weatherstrip on the back of the plate to keep it off the paint.

    Because of tools and material I had on hand, I added two #10-24 Riv-Nuts to pickup the lower two license plate mounting holes. The two stock upper mounts are M6x1.0 thread and I would have had to bought new tooling and Riv-nuts for my Riv-nutter to match them.

    There is about 2 inches clearance after you drill through the sheet metal, so with a small amount of care you won't run your drill into anything.

    The Riv-nut tool I used was a Harbor Freight Item#1210, 45 Piece Threaded Insert Nut Riveter Kit for $16.99.

    I got the HF one because it would have cost me more than that just to buy the right sized nut fixture and nuts for my high end Riv-nut tool.:eek:

    Riv-nuts (Threaded insert nut rivets) are similar to the blind rivets (Pop rivets) that you can buy in any hardware store and many car parts stores. Unfortunately, riv-nuts and the installation tool can be hard to find. The difference between Pop Rivets and Riv-nuts is that Riv-nuts have a threaded hole in them that can be used to screw conventional screws into. They are useful tool if you are ever want to securely attach a screw to sheet metal. Image 4 is a closeup of an installed Riv-nut and you can see the threads in the center of it.


    Attached Files:

  2. spiderman

    spiderman wretched

    Joined:
    Jul 5, 2009
    7,543
    1,558
    0
    Location:
    Alaska
    Vehicle:
    2010 Prius
    Model:
    II
    Nicely done.

  3. Paul58

    Paul58 Mileage Miser

    Joined:
    Jul 31, 2010
    1,126
    125
    3
    Location:
    Atlanta
    Vehicle:
    2010 Prius
    Model:
    III
    Don't know that I could bring myself to put holes in my new Prius, but that does look slick! I'm thinking of putting a couple rubber bumpers along the bottom back side of the license plate to stop it from bouncing and possibly scratching the paint.

  4. Guy in WNY

    Guy in WNY Junior Member

    Joined:
    Dec 27, 2007
    83
    17
    0
    Location:
    Western New York
    Vehicle:
    2018 Prius Prime
    Model:
    Prime Premium
    The dealership, when putting on my plates the night I bought my car, well, let’s be generous and say the shop tech was not the brightest bulb in the room. He put my plates on with regular, 10-24 or such screws, cross threading the metric plate nut in the rear hatch of the car. In fact, the one on the right was snapped off of the aluminum panel the hatch is made of. See, the reason I know all this is the plate was loose and rattling and when I went to tighten it up, the one screw was just spinning. I had to remove the inner plastic hatch panel to get my vise grips up in there to grasp the broken off plate nut before I could remove the bolt. I just used a plastic plate nut from Autozone to resecure the plate.
    The stock “nut†is just a round, threaded piece of steel broached to a short strip of aluminum which is then spot welded to the hatch panel. It holds up well when the correct bolts are used, but trying to jam in the wrong bolts (probably with an air tool) snapped it right off the hatch panel. Of course, the guy that did it is NOT going to come forward and say “Duh, I broke your plate nut off the hatch because I jammed in the wrong sized bolts with the air driver wrench and there is NO WAY TO RESECURE IT. Sorry, we should replace the rear hatch for you, but because I’m an ignorant slob and you’re just a customer, you lose, sucker!â€
    He also left a large smear of greenish axle grease on the dash when he stuck the inspection and registration stickers on the windshield. That has never come out; it left a nice stain on the dash.
    Dealers suck!

  5. xs650

    xs650 Senior Member

    Joined:
    Jul 2, 2010
    4,539
    1,433
    9
    Location:
    Northern California
    Vehicle:
    2010 Prius
    Model:
    II
    You might consider putting the bumpers on the paint instead of the plate, that way they don't keep bouncing off the paint as the plate vibrates.

  6. stream

    stream Senior Member

    Joined:
    May 12, 2008
    2,977
    452
    14
    Location:
    Long Island, NY
    Vehicle:
    2010 Prius
    Model:
    V
    I put 3 layers of electrical tape on the back of the plate, on the 2 lower corners--works great.

  7. xs650

    xs650 Senior Member

    Joined:
    Jul 2, 2010
    4,539
    1,433
    9
    Location:
    Northern California
    Vehicle:
    2010 Prius
    Model:
    II
    I think you are asking too much to expect a Toyota tech to know that Toyota uses metric fasteners.:cool:

  8. Judgeless

    Judgeless Senior Member

    Joined:
    Jun 30, 2009
    1,821
    255
    0
    Location:
    Cleveland, OH
    Vehicle:
    2010 Prius
    Model:
    IV
    I used plastic bolts on the bottom with a plastic nut. It will not scratch the paint.

    [​IMG]

    If you do not seal the front and back of that rivet the metal from the car will rust.

  9. xs650

    xs650 Senior Member

    Joined:
    Jul 2, 2010
    4,539
    1,433
    9
    Location:
    Northern California
    Vehicle:
    2010 Prius
    Model:
    II


    The aluminum rivet would act as a protective anode if I were in a rust area and that panel on the car were made of steel, but it isn't, it's aluminum as is the rivet. :cool:

    Sealant is generally a good idea, it just isn't needed in this case.

  10. Nuckz23

    Nuckz23 Member

    Joined:
    Jan 22, 2010
    127
    5
    0
    Location:
    Santa Clara, California
    Vehicle:
    2010 Prius
    Model:
    IV
    awesome job!

  11. radiocycle

    radiocycle Active Member

    Joined:
    May 10, 2007
    550
    78
    0
    Location:
    Vallejo, CA
    Vehicle:
    2012 Prius Plug-in
    Model:
    Plug-in Base
    Is that a clear plastic cover over the plate? I can't quite tell from the pic. I think that may be a state-by-state option; in California that's illegal. I've thought about a cover to protect my 'ham radio' plate though...

  12. Judgeless

    Judgeless Senior Member

    Joined:
    Jun 30, 2009
    1,821
    255
    0
    Location:
    Cleveland, OH
    Vehicle:
    2010 Prius
    Model:
    IV
    Yes it is a clear plastic cover. It does not have a boarder. I taped of the section I wanted clear and spray painted the area that is black from the inside. The front does not have the boxes cut out for the stickers.

    [​IMG]

  13. xs650

    xs650 Senior Member

    Joined:
    Jul 2, 2010
    4,539
    1,433
    9
    Location:
    Northern California
    Vehicle:
    2010 Prius
    Model:
    II
    The law on plates does vary by state, but generally you are required to keep the license number and state name visible.

    That said, what you did doesn't bother me and looks good.

    I don't run a front plate at all on my other car (they are required where I live) and haven't been bothered about it by the police in the 6+ years I have been going without.

  14. josh2008

    josh2008 Active Member

    Joined:
    Sep 2, 2008
    365
    144
    0
    Location:
    Princeton, WV
    Vehicle:
    2004 Prius
    Model:
    N/A
    :rolleyes:

  15. royvogel

    royvogel TanzMan

    Joined:
    Dec 15, 2011
    15
    2
    0
    Location:
    Smyrna, GA
    Vehicle:
    2013 Prius
    Model:
    Four
    Impressive job, thanks for sharing!

  16. dr_rock

    dr_rock Junior Member

    Joined:
    Dec 29, 2011
    28
    1
    0
    Location:
    Pennsylvania
    Vehicle:
    2011 Prius
    Model:
    Three
    Thanks much. I'll try that soon. Appreciate it.

  17. 32kcolors

    32kcolors Senior Member

    Joined:
    Jul 14, 2009
    5,683
    952
    124
    Location:
    Redondo Beach, CA
    Vehicle:
    2010 Prius
    Model:
    V
    I prefer the cleaner design of leaving the bottom holes alone. Better (thin) license plate frames have notches against which the bottom of the plate can rest. I threw away my screw covers as they're way too big and stick out like a sore thumb.

  18. macmaster05

    macmaster05 Senor Member

    Joined:
    Sep 27, 2009
    4,050
    727
    5
    Location:
    USA
    Vehicle:
    2010 Prius
    Model:
    Two
    Lmao. Why?

  19. 32kcolors

    32kcolors Senior Member

    Joined:
    Jul 14, 2009
    5,683
    952
    124
    Location:
    Redondo Beach, CA
    Vehicle:
    2010 Prius
    Model:
    V
    Just the white plate would look better than all that black, which sticks out like an eyesore.

  20. Judgeless

    Judgeless Senior Member

    Joined:
    Jun 30, 2009
    1,821
    255
    0
    Location:
    Cleveland, OH
    Vehicle:
    2010 Prius
    Model:
    IV
    The plates are not white. There is yellow, red and blue under the black.
