towing wire harness

Discussion in 'Prius c Accessories and Modifications' started by tgpii, May 18, 2014.

  1. tgpii

    tgpii Member

    Joined:
    Sep 8, 2012
    382
    63
    13
    Location:
    Tapier Lake/Orland Park, Ilinois
    Vehicle:
    2012 Prius c
    Model:
    Two
    I know I have ask this in the past and it has been asked by others. However I am going to ask. Do they have a plug and play towing wire harness for the Prius C, not the Prius but Prius c?

  2. kingnba6

    kingnba6 Active Member

    Joined:
    Mar 17, 2013
    1,018
    242
    0
    Location:
    NY
    Vehicle:
    2013 Prius c
    Model:
    One
    i havent seen any plug and play models. i have seen models that you simply splice into te run, brake and turn signals and it converts into the trailer harness.

    mertechperformance likes this.
  3. WD0AFQ

    WD0AFQ Active Member

    Joined:
    Jul 6, 2012
    619
    152
    20
    Location:
    Dexter, Mo.
    Vehicle:
    2012 Prius c
    Model:
    Two
    There will not be a "plug n play" harness. Might be a "tap in n play" setup. Got to tap into the existing wires so you will then have "plug n play". It will be a simple install when you know where to put the taps. I have not done the C yet. Did my Vibe. Took about 10 minutes and I had to use the kit with box for extra wire. Got it at Autozone. I got the wiring diagram from the Vibe forum. Maybe someone can direct you to the diagram for the C. It will be pretty simple.
    You might check the kits at the parts store and find a diagram for the C.
    Dan

    mertechperformance likes this.
  4. JimboPalmer

    JimboPalmer Tsar of all the Rushers

    Joined:
    Apr 14, 2009
    12,470
    6,862
    2
    Location:
    Greenwood MS USA
    Vehicle:
    2012 Prius v wagon
    Model:
    Three
    May I ask why you need to tow your c around often?

  5. mertechperformance

    mertechperformance Active Member

    Joined:
    May 5, 2014
    532
    126
    0
    Location:
    Nor-caL
    Vehicle:
    2013 Prius c
    Model:
    Two
    I'm assuming they're going to use their C TO tow, not GET towed? correct us both , as one of us must be wrong, ha ha. It'll tow about 1,000 even though Toyota recommends zero.

  6. JimboPalmer

    JimboPalmer Tsar of all the Rushers

    Joined:
    Apr 14, 2009
    12,470
    6,862
    2
    Location:
    Greenwood MS USA
    Vehicle:
    2012 Prius v wagon
    Model:
    Three
    Toyota only recommends 0 because you can't recommend a negative number.

  7. mertechperformance

    mertechperformance Active Member

    Joined:
    May 5, 2014
    532
    126
    0
    Location:
    Nor-caL
    Vehicle:
    2013 Prius c
    Model:
    Two
    Yet a LESS powerful car on the same platform can tow 1,000lbs... Yaris has been on again, off again tow capable, the Echo could tow 1,000...
    The same argument was had with SCION xA/xB years ago.

  8. tgpii

    tgpii Member

    Joined:
    Sep 8, 2012
    382
    63
    13
    Location:
    Tapier Lake/Orland Park, Ilinois
    Vehicle:
    2012 Prius c
    Model:
    Two
    For the Prius but not the Prius C. For Prius C you have to splice the wires.

    mertechperformance likes this.
  9. tgpii

    tgpii Member

    Joined:
    Sep 8, 2012
    382
    63
    13
    Location:
    Tapier Lake/Orland Park, Ilinois
    Vehicle:
    2012 Prius c
    Model:
    Two
    For the Prius but not the Prius C. For Prius C you have to splice the wires. Isn't tap in play and plug in play same thing? This is so I can tow a very small trailer. Not to be towed. :LOL:

  10. mertechperformance

    mertechperformance Active Member

    Joined:
    May 5, 2014
    532
    126
    0
    Location:
    Nor-caL
    Vehicle:
    2013 Prius c
    Model:
    Two
    Plug and play is very different than a tap or splice in harness.

    SGH-T889 ?

  11. xliderider

    xliderider Senior Member

    Joined:
    Apr 19, 2012
    7,842
    3,099
    0
    Location:
    Honolulu, HI
    Vehicle:
    2011 Prius
    Model:
    Three
    No, they are different. Plug and play means no wire cutting or splicing is required. All connections would be made with an adapter, which would plug into an existing wiring harness connector.

    SCH-I535

    mertechperformance likes this.
  12. mahout

    mahout Active Member

    Joined:
    Nov 29, 2010
    655
    116
    0
    Location:
    NC
    Vehicle:
    2012 Prius c
    Model:
    Two

    My guess is they're towing it behind an RV. Hope they use a tow dolly and then of course besides more safe thee dolly has the wiring to connect to the RV brake and tail lights.. If the C is used to tow a bike trilaer again only the brake lights and tail lights need to be tappee into the C wires; pretty easy just make sure the disconnect is not at the wire taps.
    There is no plug and play in the electronic sense. Just connect, test, and be off.

  13. tgpii

    tgpii Member

    Joined:
    Sep 8, 2012
    382
    63
    13
    Location:
    Tapier Lake/Orland Park, Ilinois
    Vehicle:
    2012 Prius c
    Model:
    Two
    Not tow the C, but use the C for towing! LOL

    mertechperformance likes this.
  14. JimboPalmer

    JimboPalmer Tsar of all the Rushers

    Joined:
    Apr 14, 2009
    12,470
    6,862
    2
    Location:
    Greenwood MS USA
    Vehicle:
    2012 Prius v wagon
    Model:
    Three
    I was afraid of that, not a good idea at all. short wheelbase vehicles are very bad at towing.
    [​IMG]

  15. priusCpilot

    priusCpilot Active Member

    Joined:
    Mar 6, 2012
    631
    208
    0
    Location:
    LA
    Vehicle:
    2012 Prius c
    Model:
    Four
    Curt makes a PiP harness now for the harness plug.

    I love towing with my C. I tow my Jetski with it no problems.

  16. mertechperformance

    mertechperformance Active Member

    Joined:
    May 5, 2014
    532
    126
    0
    Location:
    Nor-caL
    Vehicle:
    2013 Prius c
    Model:
    Two
    100.4" isn't too short of a wheelbase let alone for a compact/sub compact vehicle.

    For reference a long bed pickup with four doors will have a wheelbase around 160"

    A SCION iQ is 79"


    Lots of variables. just saying 100 isn;t terrible. a highlander can tow 5,000 and only has a 109.8" wheelbase...
