Immobilized ecu dead key fob

Discussion in 'Gen 3 Prius Care, Maintenance & Troubleshooting' started by EValltheway, Oct 16, 2021.

Tags:
  1. EValltheway

    EValltheway Junior Member

    Joined:
    Aug 2, 2021
    5
    1
    0
    Location:
    Alabama
    Vehicle:
    2013 Prius
    Model:
    Three
    Gen 3 2011 Prius
    My 12v battery died when I replaced it my key wouldn’t start the Prius. I replaced the battery in the key and the car wouldn’t recognize the key. I hired a locksmith to program a new key but he couldn’t get it to take. He was able to clone my key with a cloning tool and start the car. Still he couldn’t get new keys to program. I took it to a Toyota dealership and they couldn’t program my old key my new used cleared key. The tech said I needed an ecu. So I had them install a new one at the cost of $2250. Well that one won’t program either. And now they are talking about maybe having to replace other ecus. Is there any reason the transmission ecu would need to be replaced in order to program a key?

    #1 EValltheway, Oct 16, 2021
  2. rjparker

    rjparker Tu Humilde Sirviente

    Joined:
    Jun 6, 2008
    6,670
    3,870
    7
    Location:
    Texas Hill Country
    Vehicle:
    2012 Prius v wagon
    Model:
    Three
    I think you are dealing with mechanics who are not very good. I believe a pre-existing fob usually can not be reprogrammed from scratch but a new one can if you still have another good one. Otherwise they wipe everything and start with new fobs. I am going by what I have read in the past, not personal experience.

    It could be the locksmith fouled up the sequence and then had to sell you a new fob. Its not clear what you meant by "they couldn’t program my old key my new used cleared key." Old, new or used cleared fob?

    You could check The Care Care Nut youtube channel. He has a recent video about programming fobs.

    #2 rjparker, Oct 16, 2021
  3. ASRDogman

    ASRDogman Senior Member

    Joined:
    May 29, 2018
    5,273
    2,922
    0
    Location:
    Florida
    Vehicle:
    2010 Prius
    Model:
    Two
    It's not an ecu problem. It's and "OE". Operator Error.
    Apparently they don't know how to program a key.
    I hope you had them reinstall the original ECU and refund your money.
    They told you that would solve the problem, and it didn't.

    #3 ASRDogman, Oct 16, 2021
  4. EValltheway

    EValltheway Junior Member

    Joined:
    Aug 2, 2021
    5
    1
    0
    Location:
    Alabama
    Vehicle:
    2013 Prius
    Model:
    Three
    Toyota Service Total Failure. So the full story. I bought my Prius used from the dealership. I even bought the extended warranty. I dutifully brought it in for maintenance. My prius cam due for some recall repairs after my maintenance plan expired and i dropped it off. A couple weeks after the recall my check engine light came on. I took it back to Toyota and they said the hybrid battery was bad and it would cost me $6000.00 to repair, and the standard battery was also bad.The said it wouldn't restart on the batteries but would stay running.I was at work so I said no thanks and told them to just jump start it and i'll come pick it up. I took it home and parked it. Because i didn't need it as a primary driver i waited till i had the money to buy the hybrid battery. Some months later I replaced the hybrid battery with the nexcell from DR prius.I replaced the standard battery with an optima AGM. I replaced the key battery. The car still wouldn't start. I hired a locksmith but he wasn't able to program a new key. I took both my original key and a new key bought off line to toyota and they were not able to program either one. they tried new one of their keys from parts with no success. they told me i needed a new immobilizer ECU so i authorized the $2250 for the repair.
    so they called engineering again and the new diagnosis was i needed another ECU this one for the engine. I said "Have you lost your mind? Yall are just throwing parts at it and don't really have a clue." They asked me if i wanted to continue or just put it back? i said put it back. I now have a non running Prius.
    Model:Prius
    Type:Car
    Make:Toyota
    Model year:2011
    Manufacturer:Toyota Motor Corporation
    Manufactured in:Japan (Asia)
    Plant:Fujimatsu Plant
    Sequential number:356117
    Body style:HATCHBACK 4-DR
    Body type:4 Door Hatchback
    Brake - front:Disc
    Brake - rear:Drum
    Doors:4
    Driveline:front-wheel drive
    Engine series:4-Cyl. 1.8L Electric Assist
    Engine type:1.8L L4 DOHC 16V
    Fuel tank:11.90 gallon / 45.0 liter
    Fuel type:Gasoline
    Safety restraints:Dual Air Bag, Seat Belts, Knee Air Bag, Side Air Bag-1st Row, Curtain Shield Air Bag-All Rows
    Tires:195/65R15
    Trim level:Base
    Turning Diameter:34.20 ft / 10.4 m

    #4 EValltheway, Oct 25, 2021
  5. rjparker

    rjparker Tu Humilde Sirviente

    Joined:
    Jun 6, 2008
    6,670
    3,870
    7
    Location:
    Texas Hill Country
    Vehicle:
    2012 Prius v wagon
    Model:
    Three
    Wow. What a mess. I think the mistake was the assumptions made after the dual battery diagnosis followed by parking it.

    At that point the high voltage battery was still functional. All the car really needed was the 12v battery. The hv battery can't be totally dead and still allow the car to run from the dealer to your house.

    However the hv battery could have been weak in a ten year old car.

    From that point on its hard to say what happened. I would revisit the diy hv battery swap, a significant job that could have a missing step, cable, nut or even an orange plug not completely pushed in, a three step process often responsible for a no start. I would verify the new 12v installation and voltage. Most likely many 12v jump starts have occurred, I would check the 125a fuse in the engine fuse box which instantly blows on a reverse polarity jump.

    The keyfob was ok when you parked it, I suspect its failure was a guess or perhaps a misdirection because the car would not go Ready. Its possible the locksmith or subsequent dealer attempts on this cleared the existing fob registrations. To add confusion, in your first post you said the locksmith started the car, in the second he failed?

    At this point there have been so many hands on the battery and control systems that multiple problems can exist, a situation "good" mechanics have trouble with. You need to find an expert diagnostician on a Prius. I would expect a dealer would be the place, maybe not in your case based on the "full" story.

    #5 rjparker, Oct 26, 2021
    Last edited: Oct 26, 2021
  6. captj94

    captj94 New Member

    Joined:
    Jan 22, 2022
    7
    5
    0
    Location:
    washington
    Vehicle:
    2011 Prius
    Model:
    Three Touring
    Did you ever get the car fixed Im having the same kind of issue?

    #6 captj94, Jan 23, 2022
  7. bisco

    bisco cookie crumbler

    Joined:
    May 11, 2005
    105,160
    47,722
    0
    Location:
    boston
    Vehicle:
    2012 Prius Plug-in
    Model:
    Plug-in Base
    you need new batteries and ecu's? might as well total it

    #7 bisco, Jan 24, 2022
  8. EValltheway

    EValltheway Junior Member

    Joined:
    Aug 2, 2021
    5
    1
    0
    Location:
    Alabama
    Vehicle:
    2013 Prius
    Model:
    Three
    no.

    #8 EValltheway, Jul 25, 2022
  9. AzusaPrius

    AzusaPrius Senior Member

    Joined:
    May 27, 2020
    1,507
    704
    0
    Location:
    California
    Vehicle:
    2010 Prius
    Model:
    IV
    When you power up the car do you try to start it with the brake pedal pressed first try?

    When you replaced bad batteries, you need to push the start button twice without pressing the brake pedal.

    The system needs to recalibrate the ecu's
    Once that is done then power down and then try starting it normally with brake pedal pressed.

    #9 AzusaPrius, Jul 26, 2022
