Idea to fool the tire pressure sensors

Discussion in 'Gen 3 Prius Accessories and Modifications' started by CivicQc, Mar 4, 2010.

  1. Judgeless

    Judgeless Senior Member

    Joined:
    Jun 30, 2009
    1,821
    252
    0
    Location:
    Cleveland, OH
    Vehicle:
    2010 Prius
    Model:
    IV
    That was not the question.

  2. qbee42

    qbee42 My other car is a boat

    Joined:
    Mar 2, 2006
    18,058
    3,044
    7
    Location:
    Northern Michigan
    Vehicle:
    2006 Prius
    Ah, good to know. In the future I will try to avoid any extraneous useful information. :rolleyes:

    Tom

    2 people like this.
  3. bagwell

    bagwell Active Member

    Joined:
    Sep 14, 2005
    580
    43
    0
    Location:
    the woodlands, tx
    Vehicle:
    2010 Prius
    Model:
    II
    good info and I was not confused at all.

  4. teeasal

    teeasal New Member

    Joined:
    Jul 27, 2010
    420
    50
    0
    Location:
    ON, Canada
    Vehicle:
    2010 Prius
    Model:
    IV
    Sorry to revive an old thread, but, for the life of me, I can't find this damn button! The panel below the steering wheel in my Prius is as smooth as a wall!

    Is it possible that this feature of Prii in Canada had been removed due to the fact that it is a must to change into winter tires in Canada? Or is it just me, I mean mine Prius missing this "TPMS reset" button?

    Can other Canadian Prii owners double check and confirm my discovery? Thanks.

  5. Judgeless

    Judgeless Senior Member

    Joined:
    Jun 30, 2009
    1,821
    252
    0
    Location:
    Cleveland, OH
    Vehicle:
    2010 Prius
    Model:
    IV
    I have a US version of the Prius. Here is a pic of the TPMS reset button on my car.

    [​IMG]

    1 person likes this.
  6. bagwell

    bagwell Active Member

    Joined:
    Sep 14, 2005
    580
    43
    0
    Location:
    the woodlands, tx
    Vehicle:
    2010 Prius
    Model:
    II
    will any set of toyota sensors work (be seen by the computer) in the 3g prius?

  7. Judgeless

    Judgeless Senior Member

    Joined:
    Jun 30, 2009
    1,821
    252
    0
    Location:
    Cleveland, OH
    Vehicle:
    2010 Prius
    Model:
    IV
    I would bet they would. The new sensors address would have to be added to system using the TechStream software or other OBDC tools.

  8. 1aberg1@verizon.net

    [email protected] New Member

    Joined:
    Jan 15, 2011
    4
    0
    0
    Location:
    saranac lake ny
    Vehicle:
    2010 Prius
    Model:
    III
    how do you reset the sensor after putting air in tires. [email protected]

  9. qbee42

    qbee42 My other car is a boat

    Joined:
    Mar 2, 2006
    18,058
    3,044
    7
    Location:
    Northern Michigan
    Vehicle:
    2006 Prius
    It's in the owner's manual. On the Gen II, you hold in the TPMS button under the steering wheel. I believe it works the same way for your Gen III.

    Tom

  10. SlowTurd

    SlowTurd I LIKE PRIUS'S

    Joined:
    Aug 22, 2009
    1,156
    333
    0
    Location:
    nj
    Vehicle:
    2010 Prius
    Model:
    III
    is there any way to use the wires to the reset button to fool the computer?

  11. evpv

    evpv Active Member

    Joined:
    Apr 19, 2010
    670
    315
    8
    Location:
    West Coast
    Vehicle:
    2019 Prius Prime
    Model:
    Prime Plus
    Modern tire change equipment will never ruin a wheel when used correctly. Worst case scenario would be minor scratching on the lip.

    mtbiker53 likes this.
  12. cossie1600

    cossie1600 Active Member

    Joined:
    Jul 25, 2009
    898
    92
    0
    Location:
    CT
    Vehicle:
    2010 Prius
    Model:
    II
    the reset button only read the sensors that are programmed in the ECU. You have to reprogram the sensors if you swap it.

  13. qbee42

    qbee42 My other car is a boat

    Joined:
    Mar 2, 2006
    18,058
    3,044
    7
    Location:
    Northern Michigan
    Vehicle:
    2006 Prius
    True, assuming the technician knows what he is doing and actually cares.

    Minor scratching, on the other hand, opens the door to serious crevice corrosion. A big gouge will wreck your wheel immediately. With minor scratches it just takes longer.

    Tom

  14. pEEf

    pEEf Engineer - EV nut

    Joined:
    Sep 23, 2010
    720
    570
    3
    Location:
    Berkeley, CA
    Vehicle:
    2008 Prius
    Model:
    N/A
    On the Gen 3 if you want to disable the TPMS without any warning lights, disconnect the TMPS ECU and jumper pins 5 and 7 on the connector. You can do this with a small paperclip cut and bent into a U shape. Here's the connector:

    [​IMG]

    The TPMS ECU is located in the "ECU Integration Box" located behind the glovebox:

    [​IMG]

    On the Gen 2, this is much more difficult! (the black tape trick prevails!)

    Sporin, Malosos, m.wynn and 9 others like this.
  15. evpv

    evpv Active Member

    Joined:
    Apr 19, 2010
    670
    315
    8
    Location:
    West Coast
    Vehicle:
    2019 Prius Prime
    Model:
    Prime Plus
    I'm not sure where you're getting all of this. The chances of destroying a wheel during a tire change is almost zero. You're making it sound like alloy wheels are so fragile that simply changing the tires a few times wears them out. That's just not the case.

    Additionally, a tire shop with common TPMS wrenches can swap the sensors with little risk of damage. The valve stems are a strong and simple design, the electronics are heavily protected to deal with the harsh environment inside a moving wheel.

  16. pEEf

    pEEf Engineer - EV nut

    Joined:
    Sep 23, 2010
    720
    570
    3
    Location:
    Berkeley, CA
    Vehicle:
    2008 Prius
    Model:
    N/A
    FYI: You can unplug this in the winter and bypass it, then in the summer reconnect it and it will still have the programming intact. It will not need dealer attention to restore operation as long as your original sensors are still working properly. It does not have any power to it when the car is shut off, so you don't even have to disconnect the battery to tinker with it.

    SFO likes this.
  17. evpv

    evpv Active Member

    Joined:
    Apr 19, 2010
    670
    315
    8
    Location:
    West Coast
    Vehicle:
    2019 Prius Prime
    Model:
    Prime Plus
    Have you tried it on a real car pEEf?

  18. pEEf

    pEEf Engineer - EV nut

    Joined:
    Sep 23, 2010
    720
    570
    3
    Location:
    Berkeley, CA
    Vehicle:
    2008 Prius
    Model:
    N/A
    Yes, I was asked to disable it for someone. It was surprisingly easy! I had to reference the diagram though to remember what I did.

    SFO likes this.
  19. qbee42

    qbee42 My other car is a boat

    Joined:
    Mar 2, 2006
    18,058
    3,044
    7
    Location:
    Northern Michigan
    Vehicle:
    2006 Prius
    The wheel doesn't get destroyed during a tire change, unless you have an ape doing the work, which of course does happen at some tire shops. What does happen is that each cycle increases the number of tiny scratches, each of which speeds up the process of crevice corrosion.

    Where do I get this? From metallurgy. Read up on filiform corrosion if you want the details.

    Tom

  20. evpv

    evpv Active Member

    Joined:
    Apr 19, 2010
    670
    315
    8
    Location:
    West Coast
    Vehicle:
    2019 Prius Prime
    Model:
    Prime Plus
    Filiform corrosion is more commonly related to a problem with the coating process, not from damage caused by changing tires. Modern tire change machines don't even touch the lip of the wheel. You're far more likely to damage a wheel by hitting a curb or from rock damage.

    It should be perfectly safe to change tires dozens of times without damaging the wheels.

    Typical filiform corrosion:

    [​IMG]

    mtbiker53 likes this.
