Techstream Mini-VCI

Discussion in 'Fred's House of Pancakes' started by cyberpriusII, Feb 20, 2017.

  1. cyberpriusII

    cyberpriusII Prodigyplace says I'm Super Kris

    Joined:
    Oct 1, 2009
    1,135
    1,560
    0
    Location:
    Iowa
    Vehicle:
    2008 Prius
    Model:
    N/A
    Was not sure if this should go in a "normal" forum or not -- ie -- GEN 2 troubleshooting.

    I had a great deal of trouble getting Techstream to run today. I originally bought a Fogata unit a few years ago, but the Mini-VCI connector was cracked on arrival.

    It worked and I was able to pull the codes I needed (I had had it shipped overnight). But, once I got that done, I sent it back. I would have kept it. It worked fine, but I was afraid it would actually split and really break.

    So, last summer, got a check engine light. I ordered a new Mini-VCI from another firm that had top ratings. It came, but by the time it got here, the light had gone off and I never bothered to install it.

    Today, I had a check light, tried to install the Mini-VCI, it kept kicking me out at the "software registration page."

    I finally found an OBD site that gave me a code to plug in, which worked to at least get me in the evaluation mode.

    So, not being VCI-savvy, what do I need to do to get out of evaluation and into -- I don't know -- normal?

    #1 cyberpriusII, Feb 20, 2017
    Last edited: Feb 20, 2017
  2. RCO

    RCO Senior Member

    Joined:
    Aug 31, 2016
    3,709
    5,183
    0
    Location:
    Cornwall
    Vehicle:
    Other Hybrid
    Model:
    N/A
    Try calling on @bisco. He seems to know a lot about most things Prius and if not he's bound to know someone who does. As ever I wish you good luck!

    #2 RCO, Feb 22, 2017
    bisco likes this.
  3. bisco

    bisco cookie crumbler

    Joined:
    May 11, 2005
    107,699
    48,945
    0
    Location:
    boston
    Vehicle:
    2012 Prius Plug-in
    Model:
    Plug-in Base
    i wish. how did this post get so lost? i would unplug everything, shut down and start over. but you're gonna need patrick or andrew or someone of their ilk if that doesn't work.

    #3 bisco, Feb 22, 2017
    RCO likes this.
  4. ETC(SS)

    ETC(SS) The OTHER One Percenter.....

    Joined:
    Oct 28, 2010
    7,673
    6,492
    0
    Location:
    Redneck Riviera (Gulf South)
    Vehicle:
    Other Non-Hybrid
    Model:
    N/A
    #4 ETC(SS), Feb 23, 2017
  5. Stevewoods

    Stevewoods Senior Member

    Joined:
    Jun 10, 2014
    647
    983
    0
    Location:
    Seattle, WA
    Vehicle:
    2008 Prius
    Model:
    II
    My computer knowledge is about like the boss.

    [​IMG]

    But, have you tried deleting and reinstalling, or installing a completely different version from one of the many floating around the web.

    #5 Stevewoods, Feb 23, 2017
    cyberpriusII likes this.
  6. cyberpriusII

    cyberpriusII Prodigyplace says I'm Super Kris

    Joined:
    Oct 1, 2009
    1,135
    1,560
    0
    Location:
    Iowa
    Vehicle:
    2008 Prius
    Model:
    N/A
    Well, hope my "evaluate" holds out, as I am not getting any answers.

    I have read pretty much all I can find online everywhere. Apparently, if it goes to evaluate, you have 29 uses before it locks you out. There is supposedly a way to reset that....but...

    Anyway, one thing I read is to search and destroy your entire computer because "just uninstalling" does not get rid of previous programs.

    When I bought the previous device, I installed V. 7xxx on the laptop. When I returned the device, I deleted that version of Techstream. But, as I read, not all of it was gone. I manually found all pieces I could and deleted all of them. I then uninstalled and deleted all pieces of the program I installed last week. I then reinstalled the new version, but was still stuck at the registration screen.

    Oh, well. It works for the time being.

    #6 cyberpriusII, Feb 25, 2017
  7. Currahee

    Currahee Member

    Joined:
    Apr 9, 2016
    103
    33
    0
    Location:
    CT
    Vehicle:
    2007 Prius
    Model:
    II
    If you have or can acquire an installation disc of Windows XP you can use VirtualBox and have a sandboxed, discardable operating system upon which to run Techstream. Anything running XP should not be connected to the Internet in any case, but perhaps Techstream is phoning home with the evaluation login and disabling itself. I've not had any problems running mine from VirtualBox with networking disabled, inside my Macbook.

    #7 Currahee, Feb 25, 2017
    Last edited: Feb 25, 2017
    pilotgrrl and RCO like this.
  8. bwilson4web

    bwilson4web BMW i3 and Model 3

    Joined:
    Nov 25, 2005
    27,123
    15,389
    0
    Location:
    Huntsville AL
    Vehicle:
    2018 Tesla Model 3
    Model:
    Prime Plus
    That was what disabled it the last time I tried to run TechStream remotely from inside the house. Once it 'touched' the Internet, it 'bricked itself.'

    Bob Wilson

    #8 bwilson4web, Feb 25, 2017
  9. Trollbait

    Trollbait It's a D&D thing

    Joined:
    Feb 7, 2006
    21,720
    11,316
    0
    Location:
    eastern Pennsylvania
    Vehicle:
    Other Non-Hybrid
    Something like Revo Uninstaller would find everything.

    #9 Trollbait, Feb 25, 2017
    RCO likes this.
  10. tstab

    tstab Junior Member

    Joined:
    Sep 23, 2017
    19
    13
    0
    Location:
    Hamtramck
    Vehicle:
    2008 Prius
    Model:
    N/A
    Just went through a hell of a time getting a virtualbox setup with techstream. I have Mac OSX and did as follows, I'm attaching a photo with the links... I'm to new to the forum to post links yet... I'll repost with links in breakdown later

    Bought a Mini VCI on amazon:


    Get virtualBox here: link in text photo at bottom
    Screen Shot 2017-09-23 at 7.34.43 AM.png

    Install that puppy...

    Get yourself a version of Windows XP ... i got 32bit ... Piratebay (cough cough)

    Install XP on the virtualbox... instructions here:
    link in text photo at bottom

    After it's installed go into the settings for your virtual box here:
    Screen Shot 2017-09-23 at 7.47.14 AM.png
    Under General > Advanced do bidirectional
    Screen Shot 2017-09-23 at 7.49.19 AM.png

    Under Ports: Make sure your usb is selected:

    Screen Shot 2017-09-23 at 7.49.34 AM.png


    Downloaded Techstream 12 from here: link in text photo at bottom


    Site looks sketchy but actually worked for me. Follow the instructions on getting that program running

    Most of us these days don't have optical drives so thats why I downloaded it... plus if you follow instructions you can get around the key

    Pulled the Mini VCI driver from this OneDrive account and installed it by dragging and dropping it in my virtual box and running the .exe

    link in text photo at bottom

    I had issues with java on my version... I downloaded an old version of Java 8 and drag and dropped and installed on my virtualBox

    Plugged in Mini VCI readied my car and found out my Transaxle is toast. No good deed goes unpunished. Hit me up if anyone has any questions.

    Screen Shot 2017-09-23 at 8.01.58 AM.png

    #10 tstab, Sep 23, 2017
    SFO, pizzabad, RCO and 1 other person like this.
