What is going on with my baby

Discussion in 'Gen 2 Prius Main Forum' started by Bad55Taco, Jun 23, 2018.

  1. Bad55Taco

    Bad55Taco New Member

    Joined:
    Jun 23, 2018
    15
    2
    0
    Location:
    Winterhaven fl
    Vehicle:
    2004 Prius
    Model:
    ----USA----
    OK I have a 2004 Toyota Prius the Prius has 280,000 miles I have been religious about maintaining this vehicle tires fluid changes breaks everything earlier I got the dreaded red triangle every light on my dash is lit up in the vehicle will not shift into drive or reverse naturally I first checked the 12 V battery 12 V battery was perfect as it should be because it is only a couple weeks old. Next i made sure that the coolant pump is working and yes it was working. I noticed that my rear tire was a little low so I aired it up from 20 PSI to 35 I will be taking it in to get replaced tomorrow. I checked my brakes and they are in immaculate shape so I did the next logical thing and went to Lakeland Toyota and have them read the codes. to my surprise there was none. However they did tell me that I was about 2 quarts low on oil they replace the 2 quarts of oil in the car is back to normal. Has anybody ever experienced this and by the way the traction battery is in perfect condition per Lakeland Toyota surprisingly the only thing they said was wrong was it was lo has anybody ever experienced this and by the way the traction battery is in perfect condition per Lakeland Toyota surprisingly the only thing they said was wrong was it was low on oil. Has this happened anybody?

  2. JC91006

    JC91006 Senior Member

    Joined:
    Nov 10, 2013
    14,246
    7,003
    0
    Location:
    Los Angeles, CA
    Vehicle:
    2010 Prius
    Model:
    V
    280k miles and the car is using oil, yes I've heard of that happening. Most cars will start using oil around 150k miles. Consider yourself lucky to have made it so far without oil troubles

    Aaron Vitolins and edthefox5 like this.
  3. Bad55Taco

    Bad55Taco New Member

    Joined:
    Jun 23, 2018
    15
    2
    0
    Location:
    Winterhaven fl
    Vehicle:
    2004 Prius
    Model:
    ----USA----
    I spoke too soon was driveing and the triangle came on along with the VCS light and traction light. Turned off car now won’t go into ready. Dash is lit up like a Christmas tree.


    Attached Files:

  4. ChapmanF

    ChapmanF Senior Member

    Joined:
    Mar 30, 2008
    9,490
    6,992
    0
    Location:
    Indiana, USA
    Vehicle:
    2010 Prius
    Model:
    IV
    If the car had warning lights and they didn't find any codes, they didn't do it right.

    [​IMG]

    Weird for a dealer, but dealers are weird sometimes. Any actual case of warning lights without codes (which, in all likelihood, this is not) would have to mean a quite rare wiring or ECU problem, which they would be expected to diagnose in its own right, not to say "huh, we didn't get any codes."

    -Chap

  5. ITBland

    ITBland Active Member

    Joined:
    Jun 22, 2017
    433
    260
    3
    Location:
    New Orleans, La area, US
    Vehicle:
    2011 Prius
    Model:
    Three
    Did you disconnect the battery to clear the codes to get the car to the dealer?

    audiodave and strawbrad like this.
  6. DMC-5180

    DMC-5180 Active Member

    Joined:
    Dec 1, 2013
    279
    124
    0
    Vehicle:
    2005 Prius
    Model:
    Two
    Being 2 quarts low on oil shouldn’t give you a red triangle unless you are auto-crossing driving it. 3 quarts low might though if the engine drops oil pressure (sucks air in the oil sump pickup).

    The only time I’ve been startled by a sudden red triangle and the car not moving, was one morning when I was leaving for work. I accidentally shifted into reverse and the Red triangle lit up the car went into neutral. What I did not realize at that moment was that the drivers door was ajar. After a couple minutes in panic mode. I opened the door fully while sitting there contemplating the situation, but it didn’t sink in what happened until I closed it again and the Triangle went out and all was normal again.

    Lesson learned and crisis averted.




    iPhone X ?

    ITBland likes this.
  7. ITBland

    ITBland Active Member

    Joined:
    Jun 22, 2017
    433
    260
    3
    Location:
    New Orleans, La area, US
    Vehicle:
    2011 Prius
    Model:
    Three
    Been there, done that, and in the panic of the moment, easy to not realize the door is ajar. Sometimes the simple solution is the correct solution, that certainly would explain no codes.

  8. Bad55Taco

    Bad55Taco New Member

    Joined:
    Jun 23, 2018
    15
    2
    0
    Location:
    Winterhaven fl
    Vehicle:
    2004 Prius
    Model:
    ----USA----
    No I towed it there on a trailer

  9. edthefox5

    edthefox5 Senior Member

    Joined:
    Jul 25, 2007
    8,073
    3,586
    0
    Location:
    Clearwater, Florida
    Vehicle:
    2007 Prius
    Model:
    Two
    Its probably your hybrid battery. Its amazing its lasted as long as it has. Its 14 years old.

  10. JC91006

    JC91006 Senior Member

    Joined:
    Nov 10, 2013
    14,246
    7,003
    0
    Location:
    Los Angeles, CA
    Vehicle:
    2010 Prius
    Model:
    V
    How did you make sure the coolant pump is working?

    When an inverter pump fails, the triangle will light up when the car gets hot. After it cools, the code goes away. Will come back when the car gets hot again, along with a red triangle

    SFO and Raytheeagle like this.
  11. Bad55Taco

    Bad55Taco New Member

    Joined:
    Jun 23, 2018
    15
    2
    0
    Location:
    Winterhaven fl
    Vehicle:
    2004 Prius
    Model:
    ----USA----
    So took it back today. Said I had codes c1241 c1242 and c1256 however as I explained to them and they noted the break pedal is fine not had not spongy it is perfect. Any clue on what it truest is bc I think there just taken me for a ride or trying to

  12. ITBland

    ITBland Active Member

    Joined:
    Jun 22, 2017
    433
    260
    3
    Location:
    New Orleans, La area, US
    Vehicle:
    2011 Prius
    Model:
    Three
    This is at the top of the 1241/1242 diagnostic page:
    Is the 12v battery ground cable loose/dirty where it attaches to the body? Is the connector at the brake capacitor pack (next to the battery) loose or shorting? Rule #1 of basic troubleshooting: Ask what has changed.
    So, someone's been rummaging around in the back of the car--everything OK back there? (It could just be coincidence.)

    The rest of the diagnostic for 1241/1242 tells the tech to check for:
    1. Hybrid Control DTC
    2. 12v Battery
    3. Brake Control Power Supply
    4. ABS Harness & Connectors
    5. Skid control ECU

    bisco, JC91006 and Raytheeagle like this.
  13. Bad55Taco

    Bad55Taco New Member

    Joined:
    Jun 23, 2018
    15
    2
    0
    Location:
    Winterhaven fl
    Vehicle:
    2004 Prius
    Model:
    ----USA----
    So what are you saying I should do

  14. ITBland

    ITBland Active Member

    Joined:
    Jun 22, 2017
    433
    260
    3
    Location:
    New Orleans, La area, US
    Vehicle:
    2011 Prius
    Model:
    Three
    Is the 12v battery ground cable loose/dirty where it attaches to the body? Is the connector at the brake capacitor pack (next to the battery) loose or shorting?

  15. Bad55Taco

    Bad55Taco New Member

    Joined:
    Jun 23, 2018
    15
    2
    0
    Location:
    Winterhaven fl
    Vehicle:
    2004 Prius
    Model:
    ----USA----
    Both are tight and clean. Car drives fine then the triangle vacuum light and traction light comes on yet still drives perfect. When you shut it off and try to restart all lights on dash come on and it won’t go into ready mode. Car does jump a little when the gas engine starts after it has been setting in electric mode too long. Hybrid battery is good. Car is chargeing at 14v and battery is setting at 12.7. When put into ready mode it falls to 11.9 then back to 14v. I’m thinking it’s the break accumulator. But idk

  16. ITBland

    ITBland Active Member

    Joined:
    Jun 22, 2017
    433
    260
    3
    Location:
    New Orleans, La area, US
    Vehicle:
    2011 Prius
    Model:
    Three
    Here is the diagnostic page for C1241/C1242. (Attached)
    Here is the location of the Skid Control ECU.
    Time to go look at wires, connectors and voltages. (Getting a MiniVCI and your own Techstream wouldn't hurt either.)


    Attached Files:

  17. ITBland

    ITBland Active Member

    Joined:
    Jun 22, 2017
    433
    260
    3
    Location:
    New Orleans, La area, US
    Vehicle:
    2011 Prius
    Model:
    Three
    #17 ITBland, Jul 9, 2018
    Last edited: Jul 9, 2018
  18. ITBland

    ITBland Active Member

    Joined:
    Jun 22, 2017
    433
    260
    3
    Location:
    New Orleans, La area, US
    Vehicle:
    2011 Prius
    Model:
    Three
    Not unreasonable, since this is a known problem. Any "barking" noises or unusual activity from it?

  19. Bad55Taco

    Bad55Taco New Member

    Joined:
    Jun 23, 2018
    15
    2
    0
    Location:
    Winterhaven fl
    Vehicle:
    2004 Prius
    Model:
    ----USA----
    No none it seems to come and go like it will do it I’ll reaet by unplugging battery. Then won’t show up for a week then boom it pops up. I reset it will come back the next day reset then nothing for a few days.

  20. ITBland

    ITBland Active Member

    Joined:
    Jun 22, 2017
    433
    260
    3
    Location:
    New Orleans, La area, US
    Vehicle:
    2011 Prius
    Model:
    Three
    Check all connectors and the relays for dirt and looseness--read the description of the relay problem I linked above--I've done that-unplugged a relay only to have it push the connector down into the plastic, rather than engage the tab when I put it back in--also, relays can go bad. (might be a cheap fix!) If not, the next step would be the Skid ECU, available on eBay for ~$100-ish (cheaper if you have a Pick'N'Pull)--BUT 2004 ECU only! (If it gets that far)
