Which 4 gauges do you use on your ScanGauge II?

Discussion in 'Gen 3 Prius Technical Discussion' started by rdalemercer, Jun 13, 2010.

  1. nerfer

    nerfer A young senior member

    Joined:
    Mar 1, 2006
    2,505
    232
    28
    Location:
    Chicagoland, IL, USA, Earth
    Vehicle:
    Other Non-Hybrid
    Model:
    N/A
    My understanding is that in warp stealth mode (ICE off above 42 mph) the engine is still turning, but the valves are open and no gasoline is flowing, so I think you would still see something on the RPM.

    This can be calibrated, according to the thread linked by fuzzy1 (and is now resolved, AFAIK).

  2. tumbleweed

    tumbleweed Senior Member

    Joined:
    Oct 3, 2005
    4,067
    687
    0
    Location:
    Eastern Oregon
    Vehicle:
    2010 Prius
    Model:
    V
    Yes the RPM still indicates when fuel flow is off, you can also monitor fuel flow or TPS. I usually just use the HSI indication to tell me when I'm in warp stealth, however sometimes below 42 MPH it fools me and I just glance at the tach to see if it's at 0 RPM or still at idle speed.

    The MPH and odometer readings in the scan gauge can be calibrated. I was pointing out that, in my car at least, the scan gauge MPH was right on and the car's speedometer was off and that can't be calibrated. Not a problem just an observation. :)

  3. fuzzy1

    fuzzy1 Senior Member

    Joined:
    Feb 26, 2009
    17,038
    10,012
    90
    Location:
    Western Washington
    Vehicle:
    Other Hybrid
    Model:
    N/A
    True, but when it is spinning in WS, I always see (at my speeds :)) just one number, 992 RPM. When gas is burning, RPM is higher.

    The 2010 has some hysteresis between WS and Glide, so when I'm in the speed range of uncertainty, the RPM display tells me which mode the car is in. Sometimes I have to try a little harder to knock it from WS to Glide.

  4. E-GINO

    E-GINO Active Member

    Joined:
    Dec 27, 2009
    194
    206
    2
    Location:
    Rome, Italy
    Vehicle:
    2017 Prius Prime
    Model:
    N/A
    My Scangauge set-up is usually this:

    - RPM (ICE)
    - KPH (GPS calibrated speed)
    - AVG (per trip average fuel consumption) or FlV (Xgauge for the fuel quantity)
    - AMP (Xgauge "battery amp)

    The Xgauge "Flv" gave me the opportunity to discover that there is always a difference between the fuel that I pay and the fuel that I'm getting. I'm taking note of the FlV indications before and after the refueling. The difference varied between 3% and 8%. It is not much, but IMO it explains the difference existing between Prius trip computer calculations, and real consumptions "at the pump".

  5. JThayer

    JThayer Cubic Zirconium Member

    Joined:
    Sep 23, 2009
    46
    16
    0
    Location:
    San Diego
    Vehicle:
    2010 Prius
    Model:
    IV
    It varies depending on what I want to see...most often I have these four:

    ICE RPM
    Traction Battery Current
    Water Temperature
    MPG

    Why? Because I've found that these give me a pretty good general feeling for how the car is running. But if I am interested in some particular aspect, I'll usually swap one or more for the thing(s) that I am specifically interested in. MPG is the one most likely to be swapped out (after all, there's a gauge of the dash that provides essentially the same information...)

  6. hobbit

    hobbit Senior Member

    Joined:
    Mar 23, 2005
    4,089
    468
    0
    Location:
    Bahstahn
    Vehicle:
    2004 Prius
    Model:
    N/A
    Here is why I like monitoring kilowatts and injection time.
    It's a follow-on piece to my old "sweet spot" article with a
    bit of refinement on optimal power ranges and how some internal
    calculations done in the Scangauge plays nicely into it.
    .
    One thing I'd like to see is a mapping between the Scangauge's
    notion of power output vs. the HSI in a third-gen, at various
    road speeds. Any volunteers for a little data-collection?
    .
    _H*

    2 people like this.
  7. tumbleweed

    tumbleweed Senior Member

    Joined:
    Oct 3, 2005
    4,067
    687
    0
    Location:
    Eastern Oregon
    Vehicle:
    2010 Prius
    Model:
    V
    OK, I can program an xgauge for KW and fuel injector time (although there is a note that scaling is unsure for injector time). I have a level stretch of road I can use and hopefully find a day with no wind. So I think what we need is a list of RPM, injector time, and KW at different road speeds compared to HSI bar position at those speeds - is this correct? I also need to know what speed range (i.e. 45 to 70 MPH?) and what increments (every 5 MPH?) would be useful.

    I am willing to try and collect some data over the next week or two. I have a friend who I can coerce into riding along and recording data and maybe there won't be much traffic so I think I can get some fairly good data.

    Let me know if I have the right idea, as to what is needed.

  8. lonestar

    lonestar New Member

    Joined:
    Dec 19, 2009
    17
    4
    0
    Location:
    central Texas
    Vehicle:
    2010 Prius
    Model:
    II
    I have had a Scanguage now for only a few months and have settled into using it for two main purposes. (1) Help guage more accurately how to control the gas pedal for fuel economy and (2) monitor normal operating parameters to gurarantee the engine is operating correctly. The latter consists mainly of various temperatures for upper/lower converters, I1, I2, M1, M2, and inverter coolant temp. There are a number of interesting parameters, but I have not figured yet how to use them to help with fuel economy (e.g., amp). I intend on studying Hobbit's article to look for some hints.

    I have settled on two main parameters to help with fuel economy. These I set up together with IGN on the top and GPH on bottom. These help me lock the Gen III into super highway mode, since I mainly drive above 46 mph. GPH is what it is all about. I have found out the correct values that the 2010 wants for its various GPH ranges in the best fuel economy modes, so I quit using TPS to help me identify how the two engine types are working together. I end up controlling the gas pedal to get the GPH where I want it (based on road slope and speed).

    The third one that I always have on the guage is FWT for reasons given earlier. Mainly to guarantee proper operation and knowing when the car has heated up properly.

    The 4th guage is one that I change a lot in order to see how various parameters are operating that are of interest for me at the time. I think that I will end up leaving the 4th guage setting mainly on inverter coolant temperature as a generic one that best minimally monitors proper operation. In this way, one guage will monitor ICE temperature and one guage temperature will monitor proper electric motor operation.

  9. SquareWheels

    SquareWheels "15kW or stealth" driver

    Joined:
    Sep 5, 2010
    23
    0
    0
    Location:
    London, UK
    Vehicle:
    2004 Prius
    Model:
    N/A
    Sorry to bump this thread, but I have been itching to discover:
    which parameter is the "longterm fuel trim" -- it's not INJ, surely?

    Seeing your excellent writeup of its usefulness in page 2 of your
    100k-maintenance article, in determining the effects of a bottle of
    fuel-system cleaner, I wanted to try using it too!

    BTW this is me de-lurking, hi all from London UK!

    Squarewheels.

  10. DaveinOlyWA

    DaveinOlyWA 3rd Time was Solariffic!!

    Joined:
    Apr 13, 2004
    15,140
    611
    0
    Location:
    South Puget Sound, WA
    Vehicle:
    2013 Nissan LEAF
    Model:
    Persona
    It varies a bit but normally 12 volt battery, rpm, mpg, and water temp

    1 person likes this.
  11. tedjohnson

    tedjohnson Member

    Joined:
    May 21, 2010
    347
    72
    0
    Location:
    Greenfield MA
    Vehicle:
    2017 Prius Prime
    Model:
    Prime Premium
    RPM, HP, ICE coolant temp, Inverter coolant temp

  12. derkraut

    derkraut Member

    Joined:
    Oct 8, 2006
    299
    27
    0
    Location:
    SAN
    Vehicle:
    2006 Prius
    Model:
    II
    It varies a bit but normally 12 volt battery, rpm, mpg, and water temp

  13. jstraw20

    jstraw20 Member

    Joined:
    Jul 2, 2010
    122
    18
    0
    Location:
    Long Island NY
    Vehicle:
    2007 Prius
    Model:
    N/A
    12 volt battery, rpm, ign, water temp.

  14. Judgeless

    Judgeless Senior Member

    Joined:
    Jun 30, 2009
    1,821
    255
    0
    Location:
    Cleveland, OH
    Vehicle:
    2010 Prius
    Model:
    IV
    It was odd, I received a notice that this tread received an update while I was playing around with a new OBDII device and software.

    Recently I upgraded to an android phone and was doing research on OBDII apps. I found a $4 app call Torque that works with a $30 Bluetooth OBDII adapter. Here is the default view.

    [​IMG]

    I am in the process of converting all the Scangauge XGauge codes from the spreadsheet for the 2010 Prius to this app. I have most of it figured out. Every gauge needs the PID, min, max, scale factor, unit type and the equation. I will release the file to everyone when I am done.

    4 people like this.
  15. rickkop

    rickkop New Member

    Joined:
    Feb 28, 2009
    93
    16
    0
    Location:
    Syracuse, New York
    Vehicle:
    2010 Prius
    Model:
    V
    tedjohnson;1222793]RPM, HP, ICE coolant temp, Inverter coolant temp

    Excuse me but did I read that right? Inverter coolant temp? I don't think I have that setting on my scanguage. How do you monitor inverter temp? Rick

  16. Judgeless

    Judgeless Senior Member

    Joined:
    Jun 30, 2009
    1,821
    255
    0
    Location:
    Cleveland, OH
    Vehicle:
    2010 Prius
    Model:
    IV
    [​IMG]

  17. rickkop

    rickkop New Member

    Joined:
    Feb 28, 2009
    93
    16
    0
    Location:
    Syracuse, New York
    Vehicle:
    2010 Prius
    Model:
    V
    Ok well, I don't have a clue as to how to get this on my scanguage. I guess this is just way beyond me. Rick

  18. macman408

    macman408 Electron Guidance Counselor

    Joined:
    Mar 21, 2010
    1,179
    365
    1
    Location:
    California
    Vehicle:
    2010 Prius
    Model:
    V
    It's an Xgauge; there should be directions in the manual of how to input them. You take each of the fields from this spreadsheet and enter them in, and then you can select that gauge on the gauge display.

  19. DaveinOlyWA

    DaveinOlyWA 3rd Time was Solariffic!!

    Joined:
    Apr 13, 2004
    15,140
    611
    0
    Location:
    South Puget Sound, WA
    Vehicle:
    2013 Nissan LEAF
    Model:
    Persona
    that is why i dont have them. i only have the original version of scangauge. can it be upgraded?

  20. masini

    masini New Member

    Joined:
    Dec 8, 2010
    6
    0
    0
    Location:
    boston
    Model:
    IV
    I really do not know if all that will cost to much.
